Published: November 8, 2024
By Concentric Staff Writer
After over-riding its membership, on November 4, the national organization responsible for the reliability of the bulk power grid filed with federal energy regulators a suite of proposed new standards for inverter-based resources (IBRs) such as solar, batteries, and wind, to address problems with these systems in recent years.
On November 4, the North American Electric Reliability Corporation (NERC) made four separate filings to the Federal Energy Regulatory Commission (FERC) related to IBRs. NERC filed a petition for approval of two standards related to IBR ride-through performance during system disturbances (PRC-024-4, PRC 029-1); another requiring analysis and mitigation of IBR performance issues (PRC 030-1); a petition for approval of the proposed definition of the new term “Inverter-Based Resource”; and another establishing requirements of disturbance monitoring requirements for IBRs (PRC-028-1 and PRC-002-5).
“The proposed reliability standards are an integral part of NERC’s proposed framework to address IBR performance issues in a comprehensive and holistic manner,” the organization said in the filing for disturbance monitoring requirements for IBRs. “[T]he proposed reliability standards are part of a set of standards that collectively respond to the Commission’s directives for requirements addressing IBR ride-through settings, ride-through performance, data recording, and analysis and mitigation of unexpected IBR performance,” NERC said.
NERC said there has been widespread loss of generating resources—solar photovoltaic, wind, synchronous generation, and battery storage—across multiple “system events.” For example, the Blue Cut Fire in August 2016 in San Bernardino County, California, and the Canyon 2 Fire in October 2017 in Orange County, California, demonstrated a risk to grid reliability as IBRs were unable to ride-through the events. In 2022, NERC analyzed more than 10 grid disturbances involving widespread loss of IBRs, it said.
FERC in its Order No. 901 [RM22-12], approved in October 2023, had required NERC to file the IBR standards by Nov. 4 of this year. After disagreement among members, the NERC Board of Trustees in October invoked the special authority in order to allow the organization to meet the deadline, it said.
That lack of consensus led a NERC committee during an earlier August meeting to recommend that the board invoke its special authority “to ensure that systemic reliability issues associated with IBRs are addressed in a timely manner,” according to NERC documents.
In the Western Interconnection — the power grid that spans several western U.S. states, Canada, and parts of Mexico —IBRs are on the upswing, but they have introduced a number of challenges to reliability. IBRs lack the physical inertia that is inherent to traditional synchronous resources such as coal, gas, and nuclear, creating problems such as fault-induced delayed voltage recovery. IBRs also have trouble with the frequency response that traditional generation provides to the grid.
NERC’s Board of Trustees at an October 8 technical conference successfully revised the IBR standard, allowing it to be approved under a reduced voting threshold compared to its normal voting procedures. At an August meeting in Vancouver, NERC membership was unable to reach consensus on how stringent the standards should be.
FERC’s Order No. 901 required NERC to file the standards on a three-year staggered time frame. The commission required NERC to file IBR disturbance-monitoring data sharing, post-event performance validation, and ride-through performance requirements by November 4, 2024; IBR data and model validation by November 4, 2025; and planning and operational studies for IBRs by November 4, 2026. The Commission also directed NERC to develop and submit a work plan to develop new and revised reliability standards to address the IBR issues in accordance with that timeframe.
According to minutes from the October 8 NERC technical conference, Board of Trustees member Kenneth DeFontes recommended that the board use the special authority in order to file the standards in compliance with FERC’s November 4 deadline.
“[DeFontes] reported that while much of the hard work of NERC’s stakeholders is paying off, with progress made on important IBR reliability standards through the usual standard development process, NERC does not have a clear path forward on the IBR grid disturbance ride through standard,” the minutes say.
DeFontes said the board must consider its options to meet its regulatory responsibilities but noted that the board “does not consider these options lightly.” He also recommended continued participation by NERC members and industry representatives on the standard.
The board approved a package of Milestone 2 standards for IBR “ride-through,” which refers to the capability of solar, wind, and battery devices to continue operating during temporary disturbances or faults on the electrical grid. Inverters will ride-through the disturbance and remain connected to the grid instead of disconnecting immediately when voltage or frequency deviates from normal ranges.
The Milestone 2 standards were approved under NERC’s Project 2020-02, an initiative to develop and update standards for IBRs. NERC had identified that there was a gap in existing reliability standards, which were developed for traditional synchronous generation resources such as coal, gas, and nuclear.
The goals of Project 2020-02 are to update existing standards such as protection and controls, modeling, data, and analysis to make them more suitable for IBRs. These include requirements for more accurate modeling, performance verification, and coordination of protection systems. The initiative also has the goal of defining and enhancing ride-through requirements to establish clear and consistent requirements for IBRs to ride through system disturbances without tripping off.
NERC also has the goal of ensuring an accurate representation of IBRs in grid models, seen as critical for planning and analysis of operational reliability. This includes requirements for verifying that IBR models reflect their performance in the real world.
NERC’s Project 2020-02 included modifications to the PRC-024-4 standard and the development of the PRC-029-1 standard to initiate its development (frequency and voltage ride-through requirements for inverter-based resources), but the latter standard failed to achieve consensus through the usual standard-development process, NERC said.
The NERC board discussed issues surrounding the FERC Order No. 901 directives, including whether or not the proposed reliability standard PRC-029-1 is “just, reasonable, not unduly discriminatory or preferential, in the public interest, helpful to reliability, practical, technically sound, technically feasible, and cost-justified,” according to a NERC memorandum.
On Jan. 17, NERC also submitted its Order No. 901 work plan, which consists of key milestones to meet the FERC directives by the filing deadlines. The Milestone 2 standards, in progress, focus on the development of reliability standards to address disturbance monitoring, performance-based ride-through requirements, and post-event performance validation for registered IBRs by the Nov. 4 deadline.
While Project 2020-02, which addressed generator ride-through directives from FERC Order No. 901 had created controversy, Projects 2021-04 and 2023-02 are on track for timely completion through the usual NERC standard development process, the memorandum says.
FERC’s Order No. 901 cited multiple reports of events with IBRs as the reason NERC should have reliability standards for ride-through frequency and voltage system disturbances. The standards should permit tripping of IBRs only to protect the IBR equipment in scenarios similar to when synchronous generation resources use tripping as protection from internal faults, FERC said. Exceptions should be applied to certain IBRs, and finding consensus around those directives was a part of the main issues addressed during the technical conference, according to NERC.
FERC said NERC must require registered IBRs to continue to perform frequency support during any bulk-power system disturbance and that any new or modified reliability standard must also require registered IBR generator owners and operators to prohibit momentary cessation in the no-trip zone during disturbances.
Under FERC’s order, NERC was required to submit new or modified reliability standards that establish IBR performance requirements, including requirements addressing frequency and voltage ride-through, post-disturbance ramp rates, phase lock loop synchronization, and other known causes of IBR tripping or momentary cessation.
“Therefore, we direct NERC through its standard development process to determine whether the new or modified reliability standards should provide for a limited and documented exemption for certain registered IBRs from voltage ride-through performance requirements. Any such exemption should be only for voltage ride-through performance for those existing IBRs that are unable to modify their coordinated protection and control settings to meet the requirements without physical modification of the IBRs’ equipment,” FERC said in the order.
During deliberations among NERC members, many argued that the proposed PRC-029-1 definition was too broad and ambiguous, particularly the inclusion of phrases like “entire” and “in its entirety,” when referring to a generating plant or facility. Those parties recommended revisions to clarify the definition and ensure it aligns better with Institute of Electrical and Electronics Engineers Standard 2800, which covers interconnection and interoperability of IBRs, and interconnection with associated transmission systems.
Project 2020-02 will enhance reliability by requiring entities to perform energy reliability assessments to evaluate energy assurance and develop corrective action plans to address identified risks, NERC said. These energy reliability assessments should evaluate energy assurance across operations planning, near-term transmission planning, and long-term transmission planning or equivalent time horizons by analyzing the expected resource mix availability and flexibility and the expected availability of fuel during the study period.
According to NERC, IBRs are still being designed and installed without setting their protection and controls in accordance with their physical capabilities.
NERC had solicited comments from the industry as well as original equipment manufacturers on any information on hardware-based limitations that would prevent IBRs from meeting the proposed frequency criteria within PRC-029-1. The organization said 21 individual comments were received, including six from different original equipment manufacturers of IBRs. There were concerns that a draft of PRC 029-1 proposed frequency criteria that went beyond those established in IEEE 2800-2022 and there was a concern that IBR operators would not be able to meet those proposed frequency criteria, as IBR capability limits were hardware-based and inherent to manufacturer design.
Though the organization had failed to reach consensus among its members on some of the standards, the filing of NERC’s new standards will hopefully address the issues with IBRs that have raised their head in the Western Interconnection in recent years.
—
